Detailed Description
Key Features of Low Temperature Constant Temperature Stirring Reaction Water Bath
Precise temperature control accuracy of ±0.5℃ ensures consistent results in all applications
3000W powerful heating system guarantees rapid and stable temperature adjustments
100W circulating pump circulates fluid uniformly for optimal heat distribution
Nickel-plated copper cooling coil enhances durability and heat exchange efficiency
Spacious open diameter of 285mm allows easy access to samples inside the bath
Air-cooled condenser with optional water-cooled upgrade for flexible operation
Robust cold-rolled steel body with anti-corrosion plastic coating for long-term use
Optional explosion-proof compressor and controller improve safety in hazardous settings
Technical Specifications of Low Temperature Constant Temperature Stirring Reaction Water Bath
Model AKFY-50/20: Temperature Range -20 to +99℃, Compressor Power 2485W
Model AKFY-50/30: Temperature Range -30 to +99℃, Compressor Power 2772W
Model AKFY-50/40: Temperature Range -40 to +99℃, Compressor Power 2940W
Model AKFY-50/60: Temperature Range -60 to +99℃, Compressor Power 5145W
Model AKFY-50/80: Temperature Range -80 to +99℃, Compressor Power 10879W
Model AKFY-50/120: Temperature Range -120 to +99℃, Compressor Power 16075W
Storage Capacity: Approximately 55L
Recommended Ambient Temperature: 5 to 35℃
Ambient Humidity: 60% to 80%, ventilated
Temperature Control Accuracy: ±0.5℃
Practical Open Diameter: 285mm
Discharge Volume: 10L
Stirring Method: Magnetic stirring at bottom of tank
Heating Power: 3000W
Circulating Pump Power: 100W
Cooling Coil Material: Nickel-plated copper tube
Condenser: Air-cooled (optional water-cooled)
Power Supply: 380V / 50Hz
Safety Features: Delay, overload, overheat protection
Optional Explosion-Proof Compressor and Controller
Compatible Equipment for Enhanced Performance
Magnetic Stirrers: Enhance fluid mixing uniformity to support the Low Temperature Constant Temperature Stirring Reaction Water Bath’s temperature control
Low-Temperature Circulating Pumps: Ensure efficient coolant circulation especially with the optional water-cooled condenser
Thermocouples and Temperature Sensors: Provide additional precise temperature monitoring for the Low Temperature Constant Temperature Stirring Reaction Water Bath
Explosion-Proof Accessories: Safeguard the operation of the Low Temperature Constant Temperature Stirring Reaction Water Bath in hazardous environments
Why Choose Our Low Temperature Constant Temperature Stirring Reaction Water Bath?
The Low Temperature Constant Temperature Stirring Reaction Water Bath stands out with its precise temperature control, robust build, and advanced safety features, making it perfect for pharmaceutical labs, chemical research, and material science. This water bath combines high performance with intuitive operation, providing reliable stirring and temperature stability to ensure your sensitive reactions proceed flawlessly.
Watch Product Demonstrations
Explore real-world performance and applications in our product demo videos. Visit our video library for more insights and demonstrations.
Explore Our Full Range of Low-Temperature Reaction Baths
Explore our full range of low-temperature reaction baths on the product category page
Shipping Information
We provide worldwide shipping for all laboratory equipment. Every order is carefully packaged to ensure safe delivery. If the item is in stock, it will be shipped within 3–7 business days after payment confirmation. For out-of-stock items, we will inform you of the estimated shipping time based on the specific product.
Shipping Methods: DHL, FedEx, UPS, or sea freight (depending on order size and destination)
Estimated Delivery Time:
Asia: 5–10 business days
Europe & North America: 7–12 business days
South America & Africa: 10–15 business days
Sea freight: subject to actual transit time
Tracking: A tracking number will be provided via email once the shipment has been dispatched.
Customs & Duties: Buyers are responsible for any import taxes or customs duties required by their country or region.
For bulk orders, custom packaging, or special shipping arrangements, please contact our team for personalized assistance at lab@equilrxnlab.com.
Product specifications
| Parameter | AKFY-50/20 | AKFY-50/30 | AKFY-50/40 | AKFY-50/60 | AKFY-50/80 | AKFY-50/120 |
|---|---|---|---|---|---|---|
| Temperature Range (℃) | -20～+99 | -30～+99 | -40～+99 | -60～+99 | -80～+99 | -120～+99 |
| Storage Capacity (L) | ～55 | |||||
| Best Ambient Temperature (℃) | 5～35 | |||||
| Ambient Humidity | ≥60-80% ventilation | |||||
| Temperature Control Accuracy (℃) | ±0.5 | |||||
| Practical Open Diameter (mm) | 285 | |||||
| Discharge Volume (L) | 10 | |||||
| Stirring | Magnetic stirring at the bottom of the liquid storage tank | |||||
| Safety Protection | Delay/Overload/Overheat | |||||
| Display Method | LCD digital display, button operation | |||||
| Cooling Coil | Nickel-plated copper tube | |||||
| Body Material | Cold-rolled sheet sprayed with anti-corrosion plastic | |||||
| Heating Power (W) | 3000 | |||||
| Compressor Power (W) | 2485 | 2772 | 2940 | 5145 | 10879 | 16075 |
| Circulating Pump Power (W) | 100 | |||||
| Condenser | Air-cooled condenser (optional water-cooled) | |||||
| Power Supply | 380V/50Hz | |||||
| Explosion-proof Compressor | Optional | |||||
| Explosion-proof Controller | Optional | |||||
introduce
Application Scenarios
Precise temperature control from -120℃ to +99℃ makes the Low Temperature Constant Temperature Stirring Reaction Water Bath ideal for sensitive chemical synthesis where stable and accurate thermal environments are crucial to reaction success.
Widely used in pharmaceutical research laboratories for drug formulation and development, ensuring consistent and reproducible reaction conditions to improve product quality.
Supports biochemical and enzymatic experiments by providing uniform temperature and effective magnetic stirring, which helps maintain enzyme activity and promotes crystal growth in crystallization processes.
Essential for material science research and testing, offering stable low-temperature environments needed for polymer testing, metal alloy studies, and thermal degradation analysis.
Valuable in quality control and academic research laboratories, where precise temperature regulation and safety features ensure reliable experimental outcomes.
Magnetic stirring at the tank bottom guarantees homogeneous mixing of reactants, preventing temperature gradients and improving reaction efficiency.
Suitable for industrial pilot plants and small-scale production requiring scalable low-temperature reaction baths with reliable stirring and temperature accuracy.
peculiarity
Variable Frequency Compressor
Uses a leading brand fully enclosed compressor, occupying minimal space, with high heat exchange efficiency, providing effective cooling with safety and stability.
Solution 1
Combines a rotary evaporator with a circulating water vacuum pump to form a complete and integrated system.
Louvered Cooling Window
Features a louvered design for efficient heat dissipation, allowing for rapid cooling and ensuring stable machine operation.
Solution 2
Combines a double-layer glass reactor with its own circulation system to transfer the cooling medium to the reactor for circulation. This setup enables the glass reactor to conduct low-temperature reaction experiments on materials.
