Detailed Description

Key Features

Double-layer jacketed design supports both heating and cooling for optimal reaction control
High-capacity 100L volume, suitable for scale-up or pilot production needs
Digital temperature controller with adjustable speed for precise process tuning
Powerful 400W motor enables steady stirring at 0–450 RPM
Corrosion-resistant construction using stainless steel coated agitator shaft with fluorine for high chemical compatibility
Wall thickness of 4mm (inner and outer) ensures safety under pressure up to 0.59 MPa
Customizable kettle diameter to fit different workflows and installation spaces

Technical Specifications

Reaction Volume: 100L
Material: 304 or optional 316 Stainless Steel
Wall Thickness: Inner 4mm / Outer 4mm
Motor Power: 400W
Rotation Speed: 0–450 RPM
Controller: Speed Adjustment + Digital Temperature Display
Kettle Diameter: Customizable
Working Pressure: 1 ~ 0.59 MPa
Agitator Shaft: Stainless Steel with Fluorine Coating
Discharge Valve: DN32 Ball Valve
Power Supply: 220V / 50Hz

Compatible Equipment Suggestions

Chiller or Heating Circulator: Ensures precise control of jacket temperature for exothermic or endothermic reactions
Vacuum Pump: Supports vacuum-assisted reactions or solvent removal under reduced pressure
Feeding Tank: For continuous or semi-batch feeding during extended reaction cycles
Control Cabinet: For advanced automation, PID control, and safety interlocks in industrial use
Condenser: Useful when integrating distillation or reflux functions with the double layer reactor

Performance Highlight

This Double Layer Stainless Steel Reactor provides robust thermal regulation and stirring performance for complex and demanding applications. Whether operating under vacuum, pressure, or ambient conditions, it delivers excellent thermal insulation, reliable mixing, and chemical resistance. The 100L capacity supports mid-scale synthesis or pilot trials, making it a cost-effective yet scalable solution for R&D and small-scale production.

Watch Product Demonstrations

Explore real-world performance and applications in our product demo videos. Visit our video library for more insights and demonstrations.

Explore More in Our Double Layer Stainless Steel Reactor Category
Discover more options in our Double Layer Stainless Steel Reactor category to meet your specific process needs.

Shipping Information

We provide worldwide shipping for all laboratory equipment. Every order is carefully packaged to ensure safe delivery. If the item is in stock, it will be shipped within 3–7 business days after payment confirmation. For out-of-stock items, we will inform you of the estimated shipping time based on the specific product.

Shipping Methods: DHL, FedEx, UPS, or sea freight (depending on order size and destination)
Estimated Delivery Time:

Asia: 5–10 business days
Europe & North America: 7–12 business days
South America & Africa: 10–15 business days
Sea freight: subject to actual transit time

Tracking: A tracking number will be provided via email once the shipment has been dispatched.
Customs & Duties: Buyers are responsible for any import taxes or customs duties required by their country or region.

For bulk orders, custom packaging, or special shipping arrangements, please contact our team for personalized assistance at lab@equilrxnlab.com.

Product specifications

High Pressure Reactor Equipment Specifications

Model	AKGF-5L	AKGF-10L	AKGF-20L	AKGF-30L	AKGF-50L	AKGF-100L	AKGF-200L
Reaction Volume (L)	5	10	20	30	50	100	200
Material	304 (316) Stainless Steel (Optional)
Thickness	Inner wall 4mm, outer wall 4mm (Adjustable based on pressure)
Motor Power (W)	120	200	250	250	400	400	750
Rotation Speed	0-450 RPM
Controller	Speed adjustment, digital temperature display
Kettle Diameter (mm)	Customized based on requirements
Working Pressure	(1~0.59Mpa)
Agitator Shaft	Stainless Steel coated with fluorine materials (Various types available)
Discharge Valve	DN32 Ball Valve
Power Supply	220V/50Hz

introduce

Application Scenarios

Pharmaceutical Synthesis and Crystallization
The double layer stainless steel reactor is widely used in pharmaceutical industries for precise synthesis and crystallization processes due to its excellent temperature control and vacuum capabilities.
Fine Chemical Production
In fine chemical labs and factories, the reactor supports controlled reactions involving corrosive materials, thanks to its fluorine-coated agitator and durable stainless steel structure.
Petrochemical Pilot Experiments
The 100L double layer stainless steel reactor provides reliable performance for testing reaction conditions in petrochemical research, ensuring safe handling of high-pressure operations.
Biotechnology and Fermentation Trials
With its accurate temperature and speed control, the double layer stainless steel reactor is suitable for biological reactions, fermentation optimization, and scale-up research.
Food and Additive Testing
Food-grade stainless steel and dual-layer construction make it a practical choice for thermal testing, emulsification, and mixing processes in food science laboratories.
Material Science and Nanotechnology
Ideal for dispersing nano-particles or synthesizing new materials, the double layer stainless steel reactor ensures stability under wide temperature and pressure ranges.
